KNX Gateway
KNX IoT Measurement and Control
E/IMCU0201.1

Main Functions

1. Equipped with 1 RS485 interface
2. 2 dry contact inputs
3. 1 relay output (20A)
4. 1 0-10V output (<20mA)
5. Filter table function
6. Remote real-time control capability
7. Cloud platform access
8. IP network and server time synchronization
9. Local Bluetooth debugging / timing tasks

Product Parameters

1. Bus voltage: DC21V~30V (obtained via bus)
2. Bus current: <12mA
3. Bus power consumption: <360mW
4. Power consumption: <5W
5. Green LED flashing: indicator for normal operation of the device
6. RJ45: network cable interface
7. Protection class: IP20
8. Temperature range:
   1. Operation: -5℃~+45°C
   2. Storage: -25℃~+55°C
   3. Transportation: -25℃~+70°C

Size

90*146*64mm

Installation

DIN-rail Mounted
