Main Functions

1. Switching function
2. Relative/absolute dimming function
3. Status reporting function
4. Preset value function
5. 15 scene settings
6. Sequence function
7. Combined scene function

Product Parameters

1. Bus voltage: DC21V~30V (obtained via bus)
2. Operating current: <12mA
3. Standby power consumption: <360mW
4. Auxiliary power supply: AC95V~255V, 50/60Hz
5. Operation and indication:
   1. Red LED indicator and button for assigning physical addresses
   2. Green LED flashes to indicate normal operation of the device
6. Output parameters: AC230V, 50/60Hz
7. Maximum load for 4-channel 1A: 1A per channel
8. Maximum load for 4-channel 3A: 3A per channel
9. Minimum load: 10W per channel
10. Power loss: Maximum 5W per channel

Temperature range:

1. Operation: -5℃~+45°C
2. Storage: -25℃~+55°C
3. Transportation: -25℃~+70°C

Size

90*73*64mm, 90*219*64mm

Installation

DIN-rail Mounted
