KNX IP router
Professional KNX subnet connection solution for global smart building projects. Bridges KNX TP1 and IP networks to extend system coverage, enhance communication stability, and simplify multi-area device control. Compliant with international standards, easy to configure via ETS software, and perfectly suited for European, Russian, and Asian market requirements.
More Details
KNX IP Router
E/GAIPR1.1
Main Functions
- Standard KNX IP router, supporting 4 standard tunnel connections
- Supports IP networking
- Supports custom additional physical addresses
- Supports bidirectional group address filtering
- Supports device self-programming
- Allows users to freely set message response modes
- Supports DHCP and static IP address allocation
Product Parameters
- Bus voltage: DC21V~30V (obtained via bus)
- Bus current: <12mA
- Bus power consumption: <360mW
- Auxiliary power supply: External DC9V~30V
- Power consumption: <2W
- Connection: KNXIP port 45 socket, KNXTP port KNX terminal
- Protection class: IP20
- Temperature range:
- Operation: -5℃~+45°C
- Storage: -25℃~+55°C
- Transportation: -25℃~+70°C
Size
90*37*64mm
Installation
DIN-rail Mounted
